LED Flush Mounted Light

Overview

Key Features:

Specially designed diffuser for
superior aesthetics.
• High tension springs provided for
mounting on to false ceilings.
• Field programmable driver.
• Easy to maintain and replace.
• THD<10%. • Flicker free versions also available. • Surge Immunity IEC 61000-4-5 Level 4.

FEATURES:

Material
Body -Aluminium Sheet metal,
case welded
Diffuser – Injection Moulded
Polycarbonate

Finish:

Epoxy-polyurethane Painted RAL
9010/ Custom color on request

Protection

IP-20

Weight:

4 Kg (± 10%)

Life of Light Fitting

50,000 Hrs
• LED driver has inbuilt protection from heating, short circuit, surge.

ELECTRICAL:

Voltage: 110-230V AC, 50 Hz, 1 Ph.
Wattage: 30W
LUX value at 1M: 450 lux

Environmental Test:
Comply to JSS55555

EMI/EMC
Comply to MIL-STD-461E

All specifications are for reference only. Actual product may vary depending upon the technology upgradation.
