LED Pendant Light

Overview

Key Features:

• Designed to withstand Harsh
Environments and Ambient Temp.
up to 65 Degrees.
• MTBF >40,000 Hrs.
• Encapsulated LED Drivers for
Enhanced Lifetime.
• Field-Programmable LED Drivers.
• Flicker-Free Versions also
Available.
• THD <10%. • Surge Immunity: IEC 61000-4-5, Level 4.

FEATURES:

Material
Body – Aluminium Die Casted
Diffuser – Injection Moulded
Polycarbonate

Finish:

Painted to RAL 9010
Custom finish on request

Protection

IP-56

Weight:

2 Kg (± 10%)

Life of Light Fitting

50,000 Hrs
• LED driver has inbuilt protection from heating, short circuit.

ELECTRICAL:

Voltage: 110-230V AC, 50 Hz, 1 Ph.
Wattage: 15W
LUX value at 1M: 300 lux

Environmental Test:
Comply to JSS55555

EMI/EMC:
Comply to MIL-STD-461E

All specifications are for reference only. Actual product may vary depending upon the technology upgradation.
