LED Cabin/Tube Light

Overview

Key Features:

• Designed to withstand Harsh
Environments and Ambient temp
up to 65 Degrees.
• MTBF>40000 Hrs.
• Advantage of easy maintenance
• All Silicon Gaskets.
• Field Programmable LED Drivers.
• Flicker Free Versions also
Available.
• THD<10%. • Surge Immunity IEC 61000-4-5 Level 4.

FEATURES:

Material
Body – Aluminium Die Casted
Diffuser – Injection Moulded
Polycarbonate

Finish:

Painted to RAL 9010
Custom finish on request

Protection

IP-56

Weight:

3.5 Kg (± 10%)

Life of Light Fitting

50,000 Hrs
• LED driver has inbuilt protection from heating, short circuit, surge.

ELECTRICAL:

Voltage: 110-230V AC, 50 Hz, 1 Ph.
Wattage: 30W
LUX value at 1M: 300 lux

Environmental Test:
Comply to JSS55555

EMI/EMC
Comply to MIL-STD-461E

All specifications are for reference only. Actual product may vary depending upon the technology upgradation.
